HUNGSANG-LFP-CEL40K0G8-S16P1-5760WH

Applications: Solar Energy Storage System            Cell Type: LiFePO4

No.

 Descriptions of Parameter

Data

1

Voltage Rated

DC 48V

2

Capacity Rated

120Ah

3

Power Rated

5760Wh

4

Constant Discharge Current *max.

60A; 150A peak  *optional

5

Constant Charge Current *max.

50A *Optional

6

Charge Temperature Limited

0°C -45°C/45-85%RH

7

Discharge Temerature Limited

-20°C -55 °C/45—85%RH

8

Charge & Discharge Sockets

 Same sockets

9

Battery Cycle Life

≥2000 times *IEC standard way

10

Dimensions:(LxWxH)

470mm*357mm*218mm

11

Weight

55kg

12

Resistance

50mΩ

13

Communication Protocol

RS232/RS485/CAN available on request

14

Additional Customized Functions

Bluetooth App, GPS and Active-balance-function available on request.

15

Remarks

NO M.O.Q for new buyers.

OEM&ODM order always welcome

Longer Warranty available on request.

Delivery: 7-14 days
