HUNGSANG-LFP-CEL48H4C8-S16P1-4128WH

Applications: Solar Energy Storage System            Cell Type: LiFePO4

No.

 Descriptions of Parameter

Data

1

Voltage Rated

DC 48V

2

Capacity Rated

86Ah

3

Power Rated

4128Wh

4

Working Current *Discharge

150A; 250A peak  *optional

5

Charge Current

100A *Optional

6

Charge Temperature Limited

0°C -45°C/45-85%RH

7

Discharge Temerature Limited

-20°C -55 °C/45—85%RH

8

Charge & Discharge Sockets

 Same sockets

9

Battery Cycle Life

≥2000 times *IEC standard way

10

Dimensions:(LxWxH)

575mm*400mm*220mm

11

Weight

55kg

12

Resistance

30mΩ

13

Communication Protocol

RS232/RS485/CAN available on request

14

Additional Customized Functions

Bluetooth App, GPS and Active-balance-function available on request.

15

Remarks

NO M.O.Q for new buyers.

OEM&ODM order always welcome

Longer Warranty available on request.

Delivery: 7-14 days
